Opis
Key Features
- High quality PA amplifier
- Installation PA mixer-amplifier
- 4 Microphone inputs and 1 Line input
- XLR 3p balanced, Euroblock inputs
- 4-16 ohm & constant-voltage outputs (70V and 100V)
- FM tuner and MP3 USD/SD slot
- Bass and Teble tone controls
- Ding-dong and Priority muting by VOX
- Built-in electronic protection circuitry
- Solid construction for 19” rack – 2U mounting
Tech Specs
| Type | PA mixer-amplifier | |
| Power Output (RMS) | 200W | |
| Frequency Range | 50Hz – 14kHz | |
| T.H.D. (20Hz – 20kHz) | < 1% @ 1kHz | |
| Signal-to-noise ratio | > 90 dB @ 1 kHz | |
| Zones | No | |
| Controls | Bass and Treble, Master, Volume for MIC and Line in | |
| Indicators | Power on, Signal and Clip | |
| Inputs | Microphone, XLR/F 3p Euroblock terminals Line in | |
| Outputs | 4Ω, 8Ω and 100V line, AUX | |
| Connectors | Input: 6.3mm Jack, RCA line Output: Touch-proof binding posts | |
| Phantom Power | +48V DC | |
| Other Features | FM tuner, USB and SD card slots | |
| Protections | Short circuit, thermal overload | |
| Operation Voltage | 230V AC (factory config.), 50–60 Hz | |
| Power Consumption | 220VA | |
| Cooling | Continuously speed fan, 80mm / 230V AC | |
| Dimensions (WxHxD) | 2RU spaces, 345mm depth (13.58in) | |
| Weight | 12Kg 26.46lb |
