Key Features
- 2-way passive installation speakers
- Elegant, refined and lightness design
- 6″ (1.26in) FR EU transducer
- High sensitivity 1″ HF Kapton driver
- Euroblock terminal
- Optional line transformer, 100V – 8ohm / 15W / 30W power taps
- Prepared for wall/ceiling mounting, 4x M6 inserts for “U” bracket (supplied)
- 4x M5 inserts for Wall mount support adjustable in 2 axes (optional)
- Rugged and durable 12mm birch plywood
Tech Specs
| Type | 2-Way passive installation speaker | |
| Enclosure Design | Bass reflex trapezoidal enclosure | |
| Power Output (RMS) | 140W (AES) 280W (Program) | |
| Frequency Range | 80Hz – 18kHz | |
| Nominal Impedance | 8Ohm | |
| Transducer Type | 6″ FR (1.26in) EU transducer 1″ HF (1.00in) Kapton EU transducer | |
| Dispersion | 80° conical, aluminum horn | |
| Crossover Frequency | 2200Hz | |
| Max. SPL (peak) | 116dB @ 1m | |
| Connector | Phoenix Contact® Euroblock speaker terminal I6T: 100V line transformer, 8ohm / 15W / 30W power taps | |
| Construction | 12mm brich plywood, black or white finishing | |
| Grille | Custom perforated metal grille w/ acoustic foam | |
| Installation / Rigging / Flying | 4x M6 inserts for “U” bracket (supplied) 4x M5 inserts for wall mount/ceiling support, 2-axes (optional) | |
| Dimensions (WxDxH) | 190x200x300mm 7.48×7.87×11.81in | |
| Weight | 6.0Kg 13.22lb |
