Key Features
- Compact passive 2-way speaker
- High performance, low profile elegant design
- Front loaded enclosure
- 2x 5” (1.26in VC) rubber surround MF EU transducer
- 1″ (0.98in VC) HF EU transducer
- Constant directivity 60°x60° horn
- 2x NL4 connected in parallel
- Integrated M8 threaded nuts for U-brackets (H&V)
- Ø35mm pole mount adapter (PMA205), tilt adjustment
- Rugged and durable 15mm birch plywood
- Powder coated custom perforated steel grille
Tech Specs
Tech Specs
Type | 2-way passive speaker | |
Enclosure Design | Front loaded | |
Power Output (RMS) | 200W (AES) 280W (Program) 380W (Peak) | |
Frequency Range | 65Hz – 20kHz (-10 dB) | |
Nominal Impedance | 4Ohm MF 8Ohm HF | |
Transducer Type | 2x 5″ MF (1.26in VC) rubber surround EU transducer 1″ (1.0in VC) HF EU transducer | |
Dispersion | 60°x60° (HxV) | |
Crossover Frequency | 2500Hz | |
Max. SPL (peak) | 122dB | |
Connector | Speakon NL4 in/out, parallel-connected | |
Construction | 15mm birch plywood, textured polyurea coating | |
Grille | Custom perforated metal grille w/ acoustic mesh | |
Installation / Rigging / Flying | 8x M8 inserts for “U” brackets, WB205H and WB205V Ø35mm pole mount adapter, PMA205 | |
Dimensions (WxDxH) | 170x230x430mm 6.69×16.93×9.06in | |
Weight | 7.5Kg 16.54lb |
