Opis
The BASS-F series offers a professional passive/active flyable subwoofers range
becoming the perfect choice for sound reinforcement challenges demanding high
SPL and natural-sounding bass response designed to enhance the ultra-low bass of
an existing PA system.
A perforated steel grille protects the loudspeaker and there are two side handles as
well as four points in the rear for castors mounting. The enclosure has an integrated
rigging system flyware and Ø9.8mm ball pins w/ stainless steel lanyard with PVC to
facilitate ease of mounting and there is a metal rigging frame that allows the system
to be used ground stacked or individually flown to increase its versatility combined
with the LA10 (1x 10″ line array speaker).
Key Features
- Bass reflex & flyable PASSIVE subwoofer
- Suited for 10″ line array speaker – LA10
- 1x 18″ (4in VC) LF EU transducer, 1200W AES
- Versatile, compact and coherent subwoofer
- 2x NL4 connected in parallel
- Optimized for high SPL output
- Made for an impact bass
- Prepared for stacking and flying operation
- Rugged and durable 18mm birch plywood construction
- Powder coated custom perforated steel grille
Tech Specs
| Type | Flyable & compact PASSIVE subwoofer | |
| Enclosure Design | Bass reflex | |
| Power Output (RMS) | 1200W (AES) 2400W (Program) 4800W (Peak) | |
| Frequency Range | 32Hz – 200Hz | |
| Nominal Impedance | 8Ohm | |
| Transducer Type | 1x 18″ LF (4in VC) EU transducer | |
| Crossover Frequency | 35Hz Butterworth 18dB (low cut filter) | |
| Max. SPL (peak) | 132dB @ 1m | |
| Connector | 2x NL4 in parallel | |
| Construction | 18mm birch plywood with polyurea coating | |
| Grille | Custom perforated metal grille w/ acoustic foam | |
| Installation / Rigging / Flying | Integrated rigging flyware Ø9.8mm ball pins w/ stainless steel lanyard with PVC 2 wood feet, 2 recessed side handles Prepared for castors | |
| Dimensions (WxDxH) | 540x740x520mm 21.26×29.13×20.47in | |
| Weight | 52Kg 114.64lb |
