108.HSB Platinum Hybrid Series Subwoofers

For optimum performance, the 108.HSB should be high-passed at 43 Hz. The 108.HSB’s enclosure uses marine-grade stainless steel suspension hardware and enclosure reinforcements plus a HYBRID stainless steel grille with marine capable coating. The 108.HSB also offers an array of optional marine-grade stainless steel suspension hardware including eyebolt rigging, U-Bracket, Pan / Tilt bracket and Pole Mount bracket for placement and aiming flexibility. Add solid, high-impact low end response to your system by adding the 108.HSB.

Mounting options sold separately

SPECIFICATIONS:

• Frequency Response: 43Hz – 150Hz
• Coverage Pattern: Essentially Omnidirectional
• Active Crossover Frequency : Recommended 100Hz (150Hz max)
• Inputs: 4 position barrier (Low Z mode)
• 5 position barrier (Hi Z mode)
• System Sensitivity: 88dB (half space) (1 watt-1 meter)
• Power Handling: 200 watts Continuous 400 watts Program 800 watts Peak*
  * NOTE: All system power handling rating are amplifier headroom dependent
• Nominal Impedance: 8 ohms (Low Z mode)
• High Impedance mode: One Systems 8-inch woofer
  High Impedance power taps: 150W, 75W, 37W (70Vrms) 150W, 75W (100Vrms)
  NOTE: An active 4th order Butterworth high pass filter with a corner frequency of 43Hz should be used on all systems applications. This applies to both low impedance (Low Z mode) and 70V/100V operation (Hi Z mode).
• For bi-amp operation the suggested filters are:
  4th order Butterworth high pass………43Hz
  4th order Linkwitz-Riley low pass……100Hz or higher
• System Components:
  – Low Frequency: ONE SYSTEMS 8” (1 each)
  – High Frequency: N/A
